DataMan 8050 Series Handheld Barcode Reader Features
DataMan® 8050 series readers are equipped with Cognex’s world-class barcode reading algorithms and designed to withstand harsh factory floor conditions. The best in class algorithms decode even challenging barcodes quickly and easily including Direct Part Mark (DPM) codes. And, the flexible modular design ensures the DataMan 8050 series readers are ready to meet ever changing communication needs.

DataMan 8050 Series Handheld Barcode Reader Models and Specifications
The DataMan 8050 series is available in two models, both with corded and wireless options:

DataMan 8050X. Designed to decode challenging 2-D DPM codes with near/far integrated LED illumination.
DataMan 8050. Designed to decode challenging 1-D and 2-D label-based codes.
Support Downloads

DataMan Documentation
DataMan Drawings
DataMan Software
DataMan 8050X DataMan 8050
1-D & Stacked Barcodes Yes
2-D Codes Yes
Algorithms 2DMax/1DMax+/Hotbars 2DQuick/1DMax+/Hotbars
Image Sensor 752 x 480 global shutter
Trigger Handle trigger, presentation
Status Outputs LED, beeper
Aimer Centralized LED aimer
Lens Options Fixed focus
Lighting Integrated LED with near/far optics
Communication Serial Module: RS-232, USB-CDC and USB-HID
Dimensions 210 x 155 x 85

DataMan 8050 Series Barcode Reader Symbologies
DataMan 8050 Series

1-D: UPC/EAN/JAN, Codabar, Interleaved 2 of 5, Code 39, Code 128, Code 93, PostNet, Planet Code, Australia 4-State, Japan 4-State, UPU 4-State, Pharmacode, GS1 DataBar
Postal Codes: Intelligent Mail Bar Code
2-D: Data Matrix, MaxiCode, QR Code, MicroQR Code, Aztec
Composite: (CC-A, CC-B), PDF 417, MicroPDF
