STANDARD FEATURES Print methods: Thermal Transfer and Direct Thermal Print speed: up to 6" (152mm) per second Construction: Dual-wall frame Link-OS enabled Printer Features Tool-less printhead and platen replacement OpenACCESS™ for easy media loading Quick and easy ribbon loading Simplified calibration of media Quad connectivity: USB, Parallel, Serial, and Ethernet Real-time clock LCD User Interface Zebra E3 Printhead Energy Control ENERGY STAR® qualified Link-OS™enabled Print Touch™ app Unicode compliant for multi-language printing 16 resident expandable ZPL II® bitmap fonts Two resident scalable ZPL fonts Auto-switching 100-240V power supply Head-up sensor Standard tear-off mode feature Zebra printer drivers for Windows™ Printer Specifications Resolution: 203 dpi (8 dots/mm) 300 dpi (12 dots/mm) optional Memory: 128 MB Std SDRAM memory (4 MB available to user) 256 MB Std Flash memory (56 MB available to user) Print length: 39" (990 mm) maximum Programmable print speeds of 2, 3, 4, 5, & 6 ips (51, 76, 102, 127, & 152 mm/s) Media sensors: Full width reflective and multiposition transmissive sensors Media Characteristics Maximum label and liner length: 39"/990 mm (maximum non-continuous) Maximum label and liner width: 0.75"/19 mm to 4.25"/108 mm Label Length: Minimum using tear off mode: .25" (6.3 mm) Minimum with label present sensor used - 0.50" (12.7 mm) Minimum with cutter - 1.0" (25.4 mm) Maximum media roll size: 5"/127 mm O.D. Media thickness: 0.003"/0.08 mm to 0.012" (0.305 mm) Media types: Roll-fed or fan-fed, die-cut or continuous direct thermal labels with or without black line, tag stock, continuous receipt paper, wristbands Ribbon Characteristics Outside diameter: 1.36"/35 mm Standard length: 244'/74M Ratio: 1:1 media to roll to ribbon Width: 1.33"/33.8 mm to 4.3"/109.2 mm Core inner diameter: 0.5"/12.7 mm Environmental Storage Temperatures: -40° F/-40° C to 140° F/60° C Physical Characteristics Width: 7.6"/193 mm Height: 7.5"/191 mm Depth: 10.0"/254 mm Weight: 4.9 lbs/2.2 kg Barcodes/Symbologies Barcode Ratios: 2:1 (non-rotated) and 3:1 Linear barcodes: Code 11, Code 39, Code 93, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, EAN-14, UPC-A and UPC-E with EAN 2 or 5 digit extensions, Plessey, POSTNET, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, MSI, Codabar, and GS1 DataBar (formerly RSS) 2-Dimensional: PDF417, MicroPDF-417, Code 49, Maxicode, Codablock, Data Matrix, QR code, Aztec Options and Accessories 300 dpi print resolution printing for fine detail and crisp images Wireless—802.11 a/b/g/n and Bluetooth 3.0 dual-radio Dispenser—label peel and present with present sensor Cutter for various media types RFID encoding available ZKDU and KDU Plus™ keyboard display for stand-alone printing solutions #Êͺ¶ÒÁ¢éÍÁÙÅà¾ÔèÁàµÔÁä´é·Õè -025392650-025392657-025392906 #http://www.barcoderetail.co.th/home/index.php #mail : poscsretail@gmail.co.th #Line # ID : Line : @ucw2478b and barcodepos Facebook https://www.facebook.com/retailbarcode Youtube https://www.youtube.com/channel/UCivJPcpDN2h0fibjkZ-dSAg Google+ https://plus.google.com/u/0/+pointofsalesPOS/posts
