DataMan 700 Series Handheld Barcode Reader Features
With award-winning Cognex barcode reading technology that delivers best-in-class barcode reading, the DataMan 750 series is rugged with a lightweight design that is ESD safe.

Award-winning Cognex IDMax® technology for reading easy to challenging 1-D and 2-D barcodes
Best-in-class reading performance
Built-in laser aimer for intuitive and quick alignment
ESD Safe
Rugged and lightweight design
Adjustable optics for an expanded range of code reading applications
NEXT STEPS

DataMan Setup Tool software for easy initial set up and application evaluation

Dataman 700 Series Specifications
NEXT STEPS

DataMan 750 DataMan 750s
1-D & Stacked Barcodes Yes
2-D Codes Yes
Algorithms 1DMax and 2DMax 1DMax and IDQuick
Resolution 752 x 480 global shutter
Trigger Handle trigger, presentation
Status Outputs LED, beeper, and vibration
Aimer Laser (CDRH/IEC Class II)
Lens Options 3-position (40/65/105mm) adjustable
Lighting Integrated bright field
Communication RS-232, USB, and PS/2
Dimensions 151mm x 54mm x 49mm
Drop Resistance 50 drops from 2m
DataMan 750

The power of 2DMax handles a wide range of variations to code appearance that result from degradations in DPM code quality due to differences in material types and surfaces. The model 750 also features an ESD Safe housing for electrically sensitive applications.

DataMan 750s

This reader enables fast, high performance reading of high-quality1D and 2D codes, as well as low-contrast codes on uniform backgrounds. The model 750s provides exceptional performance on labels and well-marked codes. Like the model 750, model 750s also features an ESD Safe housing for electrically sensitive applications.


DataMan 700 Series Barcode Reader Symbologies
1-D: UPC/EAN/JAN, Codabar, Interleaved 2 of 5, Code 39, Code 128, Code 93, Pharmacode, GS1 DataBar
Postal Code: POSTNET, PLANET Code, Australia 4-State, Japan 4-State, UPU 4-State, Intelligent Mail Barcode
2-D: Data Matrix, MaxiCode, QR Code and MicroQR Code.
Composite: GS1 (CC-A, CC-B), PDF 417, MicroPDF
