Fluke 2680 Series Data Acquisition Systems
20 to 120 universal analog inputs per chassis; systems to +2,000 channels
Stand-alone data logger operation with the 2686A
Large scalable LAN systems using the 2680A with 10BaseT/100BaseT
Two types of Universal Input Modules: high-isolation precision modules or fast scan modules, with 16- to 18-bit resolution
Throughput of more than 3,000 channels-per-second-per-chassis with 2680A-FAI modules
Superior thermocouple measurement accuracy (J, K, R, S, T, N, I, U, C, B)
20 digital I/O and 8 form C, 1 Amp relay output modules for direct control of equipment
Up to 300V input isolation, 1600V transient overvoltage protection (2680A-PAI)
Universal input conditioning for any input, on any channel, in any combination (V dc, V ac, Ohms, frequency, RTD, thermocouple, thermistor or current
ATA flash memory card for stand-slone operation - from 16 MB to 1 GB (2686A only)
The Fluke 2680 Series offers the choice of networked data acquisition, stand-alone data logging, or a combination of both. Choose from two basic chassis models:
The Fluke 2680A Data Acquisition System is the choice for multi-channel applications requiring reliable Ethernet communications. It features a front-end style data acquisition system that communicates and distributes data anywhere you need it to go.
The Fluke 2686A Data Logging System writes data to a memory card for easy retrieval and storage, making it ideal for remote locations and mobile or non-computer assisted data logging applications. The system comes with a 16 MB ATA memory card and supports ATA flash memory cards of up to 1 GB to provide the memory capacity you need.
